CheckSeal™ 45P is a sealant designed for wet or dry chlorine service. 45P is a highly versatile and durable self molding packing used for stuffing boxes and for all types of valves, pumps and mechanical equipment.
Office: +1 281-606-0798
Cell: +1 281-661-0512
| Item Number | Unit Size | Quantity |
|---|---|---|
| CS0856001PL | 3/4” x 4” plugs | 10 per box |
| CS0856010GL | 1012-12, 1 gal | 12 lbs |
| CS085616JBX | 1-3/8 ” x 8-1/2” , “J” stick | 16 per box |
| CS0856EKBP | 5/8 ” spiral in | 12 lbs |
| Applications | Wet or dry chlorine service CAUTION: PTFE exposed to temperature above 500°F generates free fluorine gas. |
|---|---|
| Temperature Range | -300°F to 400°F |
| Limitations | Should not be used at temps over 500°F (204°C) as PTFE can generate toxic fluoride compounds |
| Appearance | Off-white grainy sticks or paste |
| Penetration (ASTM D217) | 40-80 |
| Specific Gravity | 1.5 |
| Density (lb/gal) | 12.6 |
| Injection Characteristics | 2000 psi, flows adequately at higher pressures |
| Cure | Non-curing |
| Long Term Changes | Some loss of carrier with pressure and temperature; reinjection may be required. |
| Storage | Keep in dry area |
